Obsidio™ Conformable Embolic

Case study

Right hepatic artery pseudoaneurysm embolization

Courtesy of Dr. Abhishek Kumar I Rutgers New Jersey Medical School

Presentation

68-year-old man s/p open cholecystectomy complicated by bile duct injury and bile leak presented for percutaneous transhepatic biliary drainage. A week following right internal/external biliary drain placement, the patient returned a week later with blood in the drainage bag.

Intervention used

Right femoral arterial access was obtained and a 5 F sheath was placed. A 5 F Sos catheter was used to select the celiac artery and an angiogram was performed. Angiography demonstrated a pseudoaneurysm of a right hepatic artery branch adjacent to the biliary drain (arrow). A 2.4 F microcatheter and 0.014” wire were then used to catheterize the vessel supplying the pseudoaneurysm. The vessel was embolized with 0.2 cc of Obsidio Embolic using a slow injection rate to allow the embolic to flow distally into the pseudoaneurysm. Post-imaging depicts the Obsidio Embolic cast. A completion celiac angiogram demonstrated complete embolization of the hepatic artery pseudoaneurysm.

Outcome

The patient was discharged home 4 hours following the procedure with no recurrence of bleeding.

Scan images from Obsidio right hepatic artery pseudoaneurysm case.

Results from case studies are not necessarily predictive of results in other cases. Results in other cases may vary.
